Omega Magnus

Folder Gluer

The Omega Magnus series of folder-gluers impresses as the specialist for corrugated board with maximum performance and stability.

Omega Magnus

Folder Gluer

  • Maximum performance and efficiency in corrugated board processing thanks to belt speeds of up to 300 m/min
  • High flexibility thanks to working widths from 240 to 2,300 mm
  • Reliable processing of a wide range of materials, from E, B, C, and double-wall corrugated board up to 1,200 g/m² heavy solid board
  • Seamless process integration through the flexible connection to peripheral devices for a fully automated workflow
  • Minimal setup times and high ease of use thanks to a modern operating concept, fully automated processes, and a central job memory

Stability and Performance – The Specialist for Corrugated Packaging

The Omega Magnus series is specifically designed for processing corrugated board. With its tailor-made technical solutions and robust construction, it offers precisely the performance and stability required for efficient corrugated board production.

A modern operating concept, automated setup processes, and the central job memory reduce setup efforts to a minimum. The result: significantly shorter job changes and easy, safe handling.

The Omega Magnus proves its flexibility when processing a wide range of corrugated and solid board. It is available in four different infeed widths.

Integrate the Magnus seamlessly into your production process with tailor-made peripheral modules and deliver perfect results of the highest quality to your customers.


The Perfect Match for Nearly Every Application in Folding Box Production

Packaging for industry

  • Displays
  • Moving boxes
  • Parcel boxes
  • Secondary packaging of all kinds

Packaging for personal care products

  • Health and care products (OTC)

Packaging for food products

  • Fresh produce
  • Dairy products
  • Cereals
  • Snacks
  • Beverage cartons

Packaging for non-food products

  • Household appliances
  • Electronics
  • Toys
  • Cleaning products
  • DIY products

Technical Data of the Omega Magnus

Omega Magnus 165 | 185 | 210 | 230

Max. Production Speed

300 m/min

Min. Blank Size

240 | 240 | 240 | 240 mm

Max. Blank Size

1,650 | 1,850 | 2,100 | 2,300 mm

Substrate Range Cardboard

300 – 1,200 g/m²

Substrate Range Corrugated Board

N, F, E, C, B, EC, EB
Corrugated Board up to a thickness of 7 mm
